034Motorsport B8/B8.5 Audi S4/S5 & Q5/SQ5 3.0 TFSI Performance Software

034-30-TFSI-S1

034Motorsport is proud to unveil an all-new line of Performance Software for B8/B8.5 Audi S4/S5 & Q5/SQ5 models equipped with the powerful 3.0 TFSI Supercharged V6 engine!

Flashed directly through your vehicle’s OBD-II port, 034Motorsport’s proprietary calibrations for the Simos 8 ECU safely and effectively increase the power output of the 3.0 TFSI engine. The result is a noticeable improvement in acceleration and throttle response, without any sacrifice in driveability or reliability.

034Motorsport's 3.0 TFSI Performance Software was developed entirely in-house on 034Motorsport's Development B8 Audi S4. The calibrations were then refined on multiple enthusiast-owned B8/B8.5 Audi S4/S5 vehicles before release.

Software Features

Dyno Proven Gains
Increased Horsepower & Torque Throughout the Powerband
Acceleration Enhancements
Improved Power Delivery, Acceleration, and Driving Characteristics
Multiple Octane Support
Available in 91 Octane, 93 Octane, and 100 Octane Calibrations
Faster Throttle Response & Improved Precision
Refined Throttle Mapping for Enhanced Throttle Response & Precision
Raised Rev Limit
Raised RPM Limit to 7,200 for Broader Powerband
Speed Limiter Removed
Speed Limiter Removed for Increased Top Speed
Track Tested
Track-Tested Calibrations Ensure Consistent Power Delivery
Port Flashing
Flashed Directly Via the Factory OBD-II Port


034MOTORSPORT 3.0 TFSI SUPERCHARGED SIMOS 8.4 & 8.5 PERFORMANCE SOFTWARE COMPARISON

Stage Fuel Max HP Max TQ Max HP Gain Max TQ Gain Rev Limiter* Speed Limiter
Stock 91 Oct 332 HP 318 TQ NA NA 6,500 RPM 150 MPH
Stage 1 91 Oct 430 HP 374 TQ 98 HP @ 7,100 RPM 72 TQ @ 7,100 RPM 7,200-7,400 RPM
Stage 1 93 Oct 438 HP 374 TQ 106 HP @ 7,100 RPM 78 TQ @ 7,100 RPM 7,200-7,400 RPM
Stage 1 100 Oct 444 HP 374 TQ 112 HP @ 7,100 RPM 83 TQ @ 7,100 RPM 7,200-7,400 RPM
Stage 1 104 Oct 453 HP 378 TQ 121 HP @ 7,100 RPM 89 TQ @ 7,100 RPM 7,200-7,400 RPM
Stage 2 91 Oct 450 HP 387 TQ 118 HP @ 7,100 RPM 87 TQ @ 7,100 RPM 7,200-7,400 RPM
Stage 2 93 Oct 455 HP 389 TQ 123 HP @ 7,100 RPM 91 TQ @ 7,100 RPM 7,200-7,400 RPM
Stage 2 100 Oct 465 HP 400 TQ 133 HP @ 7,100 RPM 98 TQ @ 7,100 RPM 7,200-7,400 RPM
Stage 2 104 Oct 470 HP 406 TQ 138 HP @ 7,100 RPM 102 TQ @ 7,100 RPM 7,200-7,400 RPM
Stage 2+ 91 Oct ** TBD ** TBD ** TBD ** TBD 7,400-7,600 RPM
Stage 2+ 93 Oct ** TBD ** TBD ** TBD ** TBD 7,400-7,600 RPM
Stage 2+ 100 Oct ** TBD ** TBD ** TBD ** TBD 7,400-7,600 RPM
Stage 2+ 104 Oct ** TBD  ** TBD ** TBD ** TBD 7,400-7,600 RPM
Stage 2+ E40 540 HP 491 TQ 208 HP @ 7,100 RPM 174 TQ @4,720 RPM 7,400-7,600 RPM


*If you have an automatic or DSG transmission rev limiter increases in the ECU will not change your maximum shift RPM. To increase the shift points you need performance TCU software as well

**Some octane variants are fully developed but have not yet undergone our dyno data colection process and as such the peak increases and power numbers are not yet listed, but you can expect similar gains to the difference of the octanes we have provided the full data collection and dyno information for.



034MOTORSPORT 3.0 TFSI SUPERCHARGED SIMOS 8.4 & 8.5 PERFORMANCE SOFTWARE STAGE DESCRIPTIONS

STAGE 1

034Motorsport Stage 1 Performance Software for the B8/B8.5 Audi S4/S5/Q5/SQ5 3.0 TFSI is engineered to safely increase horsepower and torque with no hardware modifications required. 034Motorsport's proprietary calibrations increase boost by controlling the supercharger bypass, while optimizing timing and fueling maps to extract additional power from the 3.0 TFSI engine.

Stage 1 Performance Software features a higher redline of 7,200 RPM, resulting in a broader powerband and greater peak horsepower figures than available with the factory 7,000 RPM maximum engine speed. In addition to power improvements, 034Motorsport's engineers spent a significant amount of time refining the throttle mapping in both Dynamic and Comfort modes to provide improved throttle response and allow for more precise throttle modulation. Stage 1 Performance Software also enables left foot braking, which allows for further control of the vehicle when driving on track.

034Motorsport 3.0 TFSI Performance Software is flashed via the factory OBD-II port, and does not require any physical modification of the factory ECU. Stage 1 is available in 91 Octane, 93 Octane, 100 Octane, and 104 Octane files.

STAGE 2

034Motorsport Stage 2 Performance Software for the B8/B8.5 Audi S4/S5/Q5/SQ5 3.0 TFSI is engineered to further increase horsepower and torque output over Stage 1 levels with the addition of 034Motorsport's 3.0 TFSI Supercharger Pulley Upgrade. The Supercharger Pulley Upgrade allows for increased boost pressure from the factory Eaton TVS1320 Supercharger throughout the powerband, while 034Motorsport's proprietary calibrations safely yield additional power from the 3.0 TFSI engine.

Stage 2 Performance Software features a higher redline of 7,200 RPM, resulting in a broader powerband and greater peak horsepower figures than available with the factory 7,000 RPM maximum engine speed. In addition to power improvements, 034Motorsport's engineers spent a significant amount of time refining the throttle mapping in both Dynamic and Comfort modes to provide improved throttle response and allow for more precise throttle modulation. Stage 2 Performance Software also enables left foot braking, which allows for further control of the vehicle when driving on track.

034Motorsport 3.0 TFSI Performance Software is flashed via the factory OBD-II port, and does not require any physical modification of the factory ECU. Stage 2 is available in 91 Octane, 93 Octane, 100 Octane, and 104 Octane files.

STAGE 2+

034Motorsport Stage 2+ Performance Software for the B8/B8.5 Audi S4/S5/Q5/SQ5 3.0 TFSI is engineered to further increase horsepower and torque output over Stage 2 levels with the addition of 034Motorsport's 179 or 190mm Lower Pulley in addition to our upper pulley. The Supercharger Pulley Upgrade allows for increased boost pressure from the factory Eaton TVS1320 Supercharger throughout the powerband, while 034Motorsport's proprietary calibrations safely yield additional power from the 3.0 TFSI engine.

Stage 2+ Performance Software features a higher redline of 7,400 RPM, resulting in a broader powerband and greater peak horsepower figures than available with the factory 7,000 RPM maximum engine speed. In addition to power improvements, 034Motorsport's engineers spent a significant amount of time refining the throttle mapping in both Dynamic and Comfort modes to provide improved throttle response and allow for more precise throttle modulation. Stage 2+ Performance Software also enables left foot braking, which allows for further control of the vehicle when driving on track.

034Motorsport 3.0 TFSI Performance Software is flashed via the factory OBD-II port, and does not require any physical modification of the factory ECU. Stage 2+ is available in 91 Octane, 93 Octane, 100 Octane, 104, and E40 Octane files.

034MOTORSPORT 3.0 TFSI SUPERCHARGED SIMOS 8.4 & 8.5 PERFORMANCE SOFTWARE DYNO CHARTS


Select Dyno Chart:





034MOTORSPORT 3.0 TFSI SUPERCHARGED SIMOS 8.4 & 8.5 PERFORMANCE SOFTWARE HARDWARE REQUIREMENTS



Stage Required Modifications Recommended Modifications
Stage 1
  • No hardware required

Stage 2

Stage 2+

  • Better tires




034Motorsport Dynamic+ End User Flashing Kit

034Motorsport's Dynamic+ End User Flashing Kit allows customers to install their 034Motorsport Dynamic+ Performance Software themselves. In addition, End User Flashing allows Dynamic+ Performance Software customers to receive and install software updates and revisions, flash back to stock, or upgrade to the next stage of performance software for their vehicle.

Requirements for End User Flashing:

  • Windows 10 Laptop with Available USB Port
  • Power Supply for Laptop
  • Secure Wired (Or Very Stable WiFi) High-Speed Internet Connection
  • CTEK Trickle Charger (Or Similar)
  • Available Electrical Outlets

034Motorsport End User Flashing Kit Contents:

  • 034Motorsport OBD-II Adapter
  • USB-A to USB-B Cable
  • Carrying Case
  • User Credentials (Provided Via Email)





EMISSIONS DISCLAIMER

  • This product is sold for racing and off-road use only.
  • This product is not CARB or EPA compliant, this product is not authorized for use in California on smog controlled vehicles.
  • By purchasing this product, you understand this product is sold for competition use on closed roads and is not legal for use in highway or street vehicles.
